STC-MCS891U3V

A high-performance imaging solution made for precise applications needing accuracy, speed, and dependability is the Omron STC-MCS891U3V camera. The sophisticated 1″ IMX255 color picture sensor is the foundation of this camera, which has an 8.8 MP resolution and a sturdy global shutter. The STC-MCS891U3V is perfect for demanding real-time imaging operations because it can support high frame rates of up to 42.3 fps and produces a clean output of 4096 x 2160 pixels.

The camera complies with GenICam and USB3 Vision requirements by integrating a USB 3.0 interface with secure lock connectors for reliable, fast data transfer. While capabilities like pixel defect correction, 2×2 binning, and region of interest (ROI) functionality improve image quality and performance in a variety of settings, its small form factor and compatibility with C-mount lenses offer versatility in integration.

With its advanced thermal management system, the STC-MCS891U3V is built to last even under demanding conditions. Because there is no optical filter, customers can customize the system to meet certain wavelength needs. In order to serve a broad range of industrial, scientific, and inspection applications, the camera also supports color and monochrome imaging.

Features:

• USB3 Vision CompliantGenicam Compliant
• Color and Monochrome
• High Frame Rates
• Global Shutter Sensors
• Pixel Defect Correction
• USB 3.0 Interface w/ Lock Connectors
• Small Form Factor
• 2×2 Binning and ROI
• Superior Thermal Design
