STC-MBS70BU3V

High-performance industrial monochrome cameras like the Omron STC-MBS70BU3V are made for demanding applications that need speed and accuracy. With its 7.1 MP resolution and
3216 x 2208 pixel array, this camera produces images that are crisp and detailed. Its 1.1″ image sensor and 4.5 µm pixel size guarantee outstanding sensitivity and clarity for precise data collection.

For quick image workflows, the USB 3.0 interface offers high-speed data transfer with a maximum frame rate of 51.2 fps. Applications like automation, inspection, and machine vision benefit greatly from the global shutter’s ability to catch moving objects without distortion.

The camera has wide compatibility with industry-standard optics thanks to its C-mount lens arrangement. Without the drawbacks of linear scanning, it uses an area scan type for thorough image acquisition. The camera’s optical filter-free design maximizes its versatility in a variety of wavelengths and lighting conditions.

Small, sturdy, and tailored for industrial settings
